用处与简单/Brief Introduction：

全电脑智能液压泵式膏体酱灌装线线机这是工厂不适应股票市场需要量研发的新產品。设备用途SUS304不绣钢液压泵式量值溯源泵来执行灌装线线，且集电脑智能上盖、电脑智能旋盖、有限公司电气设备为集成，区域经济很实用，征地赔偿绿地面积小，大范围用途于药业有限公司、食品加工、农约、纸业、化装品等制造业的溶剂包装箱，契合GMP正规必须。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

优势/characteristic：

◆用于液压泵式收费泵运行分装，应用各个胶状度固体，精确高；泵的设计用于快接式拆解部门，尽可能使清理、清洁消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆齿轮泵式计量检验泵气缸环面料依据领域及液态体材料的不同于选用硅胶，四氟氯乙烯或一些面料，特殊的施工地点选用淘瓷面料。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC把控程序，直流变频可控硅调压，自主化地步高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不罐装，主动计数器功能表。Lack of bottle filling, automatic counting function◆装量采取调节方面，可是次采取调节所有的收费泵的充填量，也可真对个个收费泵采取微幅采取调节；实操便利，采取调节如何快速。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆装灌线针头设置有防渗漏装备，充填时潜泳到瓶底装灌线，迟滞升，避免 导致气泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆空机可实用差异的规格的可乐瓶，优化非常简单，可在瞬时光内实现。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆设备按GMP需要结构设计。The machine designed according to the requirements of GMP

技木参数设置/technic parameter：

适用于水瓶座尺寸Size of bottles	20-1000ml（依据标准定制）20-1000 - ml (according to your need）
应用瓶里截面积Apply the bottle diameter	¢20-¢150mm
适用人群盖子年纪Apply the lid specifications	¢20-¢70mm
生孩子力量 production capacity	四头装灌：1000-2500瓶/时间 Four filling head: 1000-2500 bottles per hour 八头灌装设备：2500-4000瓶/分钟 Eight head filling: 2500-4000 bottles per hour 12头灌装生产线：4000-6000瓶/小时左右 12 head filling: 4000-6000 bottles per hour
装量随机误差The load error	±1%
旋盖适合率Screw cover percent of pass	≥99%
电power supply	380V，50HZ
瓦数power	3.0KW
安全阀gas sources	0.4-0.75MPA
的速度把控好speed control	直流变频可控硅调压variable speed
