主要用途与间介：Purpose and introduction

滤油机适在于对30-500ML一系列钢化泡沫可塑料饮料瓶、泡沫可塑料饮料瓶的装罐封好。采取往来账联系式活塞式对其进行装罐，电滋振荡器送盖，还是可不可以轧盖(铝合金式)或旋盖(泡沫可塑料盖)封好，还是可不可以和之前之后的制造研发工序装置连接组建制造线，再者还是可不可以选够百级层流罩。This machine is suitable for the filling and sealing of 30-500ml series glass bottles and plastic bottles. The reciprocating between piston filling, electromagnetic oscillation send cover, cover (metal) can be rolled or screw cap (plastic cap) sealing. Can produce and the produce of the process equipment before and after connecting line. In addition, the laminar flow hood is available for selection.

显著特点：characteristic

装量准确度，杜尽滴漏问题。缺瓶不灌装设备。 变頻控速。 主动性信息显示记数作用与功效。 机床均按GMP的标准设计制作。The filling amount is accurate, as Du drip. Lack of bottle does not fill. Frequency control of motor speed. Active display count. The machine according to the GMP request design.

的技术指标/technical parameters：

型号 model	NQGX30-500
可用于规格尺寸Cutting dimension	30-500ml
主产地本事Production capacity	80-200瓶/分（罐/分）80-200 bottles/min (cans/min)
灌装设备高精准度 Filling accuracy	≤±1%
交流电源 Power	380V/50Hz
旋（轧）盖率Spin (rolling) cover rate	≥99%
功率power	3.0 kw
物理毛重 Machine weight	1500 kg
外形尺寸 boundary dimension	3000*1100*1700mm
